Description
• Water loading: With solenoid valve
• Chimney: Removable flue gas exhaust grille made of cast iron
• Knobs: Made of aluminum with IPX5 water protection
• Floor: Made of AISI 304 stainless steel, thickness 20/10 mm
• Gas Kit: Natural gas conversion kit 30/50 m/bar (testing with natural gas)
• Plate material: Stainless steel
• Internal corners:90° straight. Optional H2 radius
• Net weight (kg):120
• Net volume (m3):0.508
• Gross weight (kg):140
• Gross volume (m3):0.835
• Total electrical power (kW):0.2
• Voltage (V):220-240
• Phases:1
• Electricity (A):1.5
• Frequency (Hz):50
• Cable section (mmq):3G1
• Total gas power (kW):14
• Total gas power (Kcal/h):12038
• Gas connection:1/2"
• Cooking zone 1 size (LxD mm): pool bottom 680x397
• Number of tanks:1
• Liters per tub 1:60
• Bowl size 1 (mm):680x397x170
• Type of overturning: Manual
• Cold water connection size (inches):3/4"
• Cold water connection size (inches):3/4"
• Hot water pressure (bar): Max pressure 5 bar
• Dimensions (mm):800x730x870
• Packaging dimensions (mm):880x856x1109
